HS-9100
Digital Conference System |
|
|
| |
|
 HS-9100
Main Controller of Conference System : |
|
|
New design digital control: Audio signal of main
controller and desktop microphones transferred by one cable. |
|
This system can work with computer
or without computer. User can select the system manage mode
on the front panel of main unit: PC manage and main unit manage
mode. |
|
4 set of 8 PIN socket for system connection,
one main system can connect with 95 desktop delegates, 1 chairman.
Communication capacity of main system can extend to maximum
600 sets(operate with extender main system). |
|
Limit Mode: Limit on the numbers(1~9)
of delegate speech, when the numbers of opened delegates attain
to the limit, the unopened cannot speech, only if the opened
delegates turn off their microphones. But the chairman unit
shall not be subject to this restriction and can speech priority. |
|
Rotation Mode(Free Mode): Allow 1-9 people speak simultaneously. |
|
Frequency response :
40HZ～18KHz, built-in 1.5W monitor speaker, has volume adjust.
Auto tone equalizer of high and low bands; support microphone
volume and sound level adjust, maintaining good quality tone. |
|
Supports the function of video camera auto-track. |
|
Serial port (RJ-45、RS-232、RS-422、RS-485);
has telephone input signal socket can connect with telephone
coupler. |
|
Load short protect function can restrain 2G and
3G mobile phone signal interference. |
|
Power ON/OFF, Power LED, LCD Function
Display. |
|
Manage the meeting with software, support double screen display. |
| |
Voting function(yes, no, abstain)
and Electing function (single-ballot, Multiple-ballot). |
|
Power supply AC110V, Power consumption of main
unit 415W, Installation 19-inch frame. Qualified International
Conference System of safety standards, BSMI, CE and RoHS certificate. |
|
|
|
| |
 |
| |
| Chairman
Unit and Delegate Unit : |
|
Function
for Chairman and Delegate Units (HS-9700c HS-9700d) |
|
● Unique "T" type cable
design is easy to install.
● Built-in anti-vibration pad fixed microphone head,
to avoid touch and vibration noise.
● The gooseneck design microphone can restrain 2G
and 3G mobile phone signal interference
● Speak key (TALK) for the identification with the
red LED is turned on the microphone,
●
set with green LED is power supply status
available.
● Sound-receiving distance: 20～80cm, Frequency response:
40HZ～18KHZ,
●
Sensitivity: -67 dB±4dB with sensitivity adjustment,
Noise Ratio: 55dB, Maximum Voice: 115dB
● The delegate microphone will turn off automatically
after 90 seconds without any sound
●
receiving.
● Integrated with camera auto-track function.
● Dimension: 210 x 165 x 65mm, Weight: 0.9kg
|
|
|
Function
index for chairman unit (HS-9700c) |
|
|
Desktop Chairman microphone
has priority to speak (red key), conference control
host can set attention signal to remind attendance.
Priority pronunciation keys to control permanently
terminate or suspend the termination of the other
microphone .Chairman microphone system is not subject
to restrictions, and can. |
 |
|
be
placed in any position. |
| |
Equipped with a set of 3.5mm stereo
socket do recording or connected with headphones,
and a 3.5mm microphone socket with external dedicated
wired microphone. |
| |
|
|
| |
|
Function index for chairman
unit (HS-9700d) |
| |
Frequency response
: 100-13000Hz. |
 |
|
Sensitivity
: -44 ± 2dB. |
|
Reference sound-receiving distance
: 20-80cm. |
|
ON/OFF
button on the microphone. |
|
Red indicator light on the microphone. |
|
HS-9700D
microphone has the electing and voting functions.
(which needed to customized) |
|
The system power supply for all the
delegate units is provided by the main frame at
24V safe voltage. |
|
Equipped
with an earphone output jack and a REC. output jack. |
|
High quality condenser cartridge,
equipped with windshield cover. |
|
Designed
by the latest digital technology. |
|
Listening and speaking. |
|
With
8-PIN T-type interconnection cable. |
|
Built-in high fidelity
speaker and earphone jack. |
|
Extended
pipe optional. |
|
The annular red indicator
lamp could show the state of the microphone. |
|
With
camera auto-track function. |
|
It meets international
conference system standard, CE and RoHS certificate. |
|
|
|
| System
Connection Diagram : |
|
|
| Cable
Accessories: |
• 8 core 10m, Extension Cable, item: HS-10M.
• 8 core 5m, Extension Cable, item: HS-5M. |
 |
|
|
• 8 core 2+1.5m, Tee Extension Cable, item:
HS-3M.
|
 |
| |
|
|
|
| Application
Example : |
| |
 |
 |
|
|
|
|
|
|
| |
|
 |
