| 1. |
4 video inputs-2 composites and 2 S-Video. |
| 2. |
2-channel full-field digital synchronization. |
| 3. |
Special effects in each of A/B program buses. |
| 4. |
2 Video inputs mixable with composite and S-Video
sources. |
| 5. |
2 Audio/Video and S-Video recording outputs. |
| 6. |
Digital effects-Still, Strobe, Mosaic, Paint and
Negative. |
| 7. |
Chroma key and Luminance key. |
| 8. |
Selective size and position for digital effects
area and PIP windows. |
| 9. |
Picture in Picture control. (3 window sizes) |
10. |
Joystick control for altering the position of digital effect. |
11. |
96 wipe patterns. |
12. |
8 different selective back colors- White,
Yellow, Cyan, Green, Magenta, Red, Blue and Black. |
13. |
Fade control for Video and Audio. |
14. |
Video and Audio mixing. |
15. |
50 dB S/N ratio. |
16. |
Compatible with CPT-370 PC to Video Overlay. |
| |
|
