>MP4 PVR-2000A：
Memorysolution Market the PVR-2000A Video Memory Card Recorder |
|
> Catalog |
|
|
|
> Manual |
|
|
|
| You can record your favorite TV shows into the memory card, or you can transfer the encoded TV content to a Video iPod and then enjoy the TV show anytime anywhere! |
| You can use any video recorder, DVD player, camcorder, your cable- or satellite receiver as image source, convert the received or recorded analog content into MPEG-4 stream and save it to a memory card. |
| |
|
|
| You can record the TV shows and enjoy them anytime anywhere ! |
 |
Catch last night’s drama while waiting for the bus.
Watch Sunday’s big game while you fly cross-city Monday.
Watch your favorite music video on your handhold gaming device.
Move your family memories from videotape to digital. |
|
| PVR-2000A will enable you to view your most favorite TV show or homemade video while on the move. View them on your PDA, your 3rd generation mobile phone, your Sony PSP, Nintendo gaming console or your beloved Video iPod. The user-friendly GUI of the PVR-2000A lets you manage your imagery and save the content to an appropriate memory card at maximum ease. Easily transfer content once digitalized to a Video iPod. View blockbusters where you like and when you like – programmed recordings are also not a problem for the PVR-2000A. |
|
| |
| Meicheng Video Memory Card Recorder, PVR Mobile, PVR2000A are consummate, simple-to-use, advanced solutions that not only has such functions as a recordable MPEG-4 movie player, digital camcorder, MP3/AAC music player, and digital photo wallet, but they also enable you to build your own mobile database through internal 1- or 2.5-inch hard drives (depend on model). |
| Through its applications, you can extend your video experience with PDA, 3G mobile phone, Sony PSP, Nintendo game console and Video iPod. Following its friendly user interface and easy operation steps, users can record their favorite TV shows into the memory cards, or they can transfer the encoded TV content to a Video iPod and then enjoy the TV show anytime. It is small enough to fit in your pocket or purse. Thanks to the compact size (D87mm x W118mm x H32mm) of the PVR, users can carry it easily. |
| |
| PVR-2000A is a leading player in the design and manufacture of wireless multimedia home devices. PVR-2000A is fully committed to delivering a series of MPEG 4 video products such as MPEG4 IP cameras, MPEG4 media jukeboxes and MPEG 4 DV recorders. |
| |
| Video Memory Card Recorder brings you favorite TV soap to your mobile device. As one of the leading memory and flash product specialists and top market player in Europe. Memorysolution is first to market the PVR-2000A Personal Media Center in TAIWAN. New PVR-2000A looks rather unimpressive, like a somewhat oversized Card Reader/Writer. There is, however, much more to the tiny little box than meets the eye. Probably its most interesting feature is to make your favorite movie or TV content available for viewing on your mobile phone, PDA, handheld or gaming console. |
| PVR-2000A is capable to use any video recorder, DVD player, camcorder, your cable- or satellite receiver or TV set as image source, convert the received or recorded analog content into an MPEG-4 stream and save it to a memory card (or an HDD in CF-II format). Prepared that way, this content can then be viewed on a handheld or PC. The PVR-2000A processes NTSC as well as PAL signals. |
| The package contains the PVR-2000A , a multilingual (German, English, Italian, Dutch, Spanish, Japanese) instruction manual on CD, a printed manual in English language, earphones, two audio & composite video line in/out (RCA) cables, an IR remote control including a battery and a power supply. |
| Besides its function as your Video Memory Card Recorder that in no time at all converts all your old analog camcorder into a new digital one, the PVR-2000A sports further forward-looking features. Just imagine using it as a comfortable MP3/AAC/WMA-compatible Music Player, which comes with a remote control and thanks to its full support of ID3 tags leaves no information about your songs in the dark. Alternatively, make the PVR-2000A your new portable digital photo wallet - or use it professionally as a digital, mobile image database. With its compact form factor and low weight of only 160g, it easily fits into any pocket. Soon this easily managed device will become your new personal digital media center. |
| Flash storage media are available at ever-lower price tags and ever-increasing capacities. Being a central component in many MP3 players, Smartphones, PDAs and the latest must-haves, Personal Navigation Assistants (PNA), flash memory cards are already widely common. Chances are that most of us already own one in the one or the other format. PVR-2000A extends their possible field of application, bringing you some additional ROI by enhancing your personal daily experience with mobile entertainment far apart from your PC. |
| Do you want to watch video on your portable devices? The PVR-2000A works like a mini digital VCR and eliminates all fees, hassle and conversion of files. You can record live TV, your favorite movies and TV shows and watch them anytime...anywhere...on almost any portable device. Put video on your PSP , iPod , smartphone, notebook and other portables! |
|
| |
|
|
| Link a diagram example： |
Connecting to CATV
(for tuner version) |
Connecting power |
Connecting to a DVD player，VCR or camcorder ( recording) |
|
|
|
|
Video Recording Time (base
on 1GB memory card) |
Mode |
Economic |
Normal
|
Fine |
Super Fine |
640x480 |
250 minutes |
143 minutes |
111 minutes |
60 minutes |
320x240-30fps |
250 minutes |
143 minutes |
93 minutes |
77 minutes |
320x240-30fps |
250 minutes |
143 minutes |
93 minutes |
77 minutes |
320x240-3GP |
250 minutes |
143 minutes |
|
|
368x208 |
500 minutes |
400 minutes |
333 minutes |
250 minutes |
176x144-3GP |
500 minutes |
400 minutes |
333 minutes |
250 minutes |
|
|
Target Player
|
Model PVR-2000A/
|
Scaleable MPEG-4
Video Recording
|
SONY PSP
|
.MP4 (MPEG4 SP+AAC-LC;upto 768kbps
320x240@30fps)
|
Nintendo GameBoy Micro
|
.MP4 (MPEG4 SP+AAC-LC;upto 768kbps
320x240@30fps)
|
Video iPod
|
.MP4 (MPEG4 SP+AAC-LC;upto 2Mbps
320x240@30fps)
|
SmartPhone
|
.MP4 (MPEG4 SP+AAC-LC;upto 768kbps
320x240@30fps)
|
3G Phone
|
.MP4
(MPEG4 SP+AAC-LC;upto 500kbps 176x144@15fps)
|
3GP (MPEG4 SP+AMR;upto 500kbps 176x120@15fps)
|
PDA
|
.AVI (MPEG4 SP+MP3;upto 2Mbps 320x240@30fps)
|
TV
|
.MP4 (MPEG4 SP+AAC-LC;upto 3Mbps
640x480@30fps)
|
Near DVD Quality Video Playback
|
File extension
|
Mode description
|
AVI
|
X-VID; DivX 4.x,5.x; MPEG4 SP+MP3 upto 4M 720x480@30fps
|
ASF
|
Microsoft WMV9 SP@ML with WNA9 L2 up to 352x288@30fps
|
MP4
|
Quick time Compliant MPEG4+AAC stereo sound upto 4M 720x480@30fps
|
Hi-fi Music Playback
|
MP3(*.MP3)
|
MPEG-1 & 2 Layer I/II/III (MP3) up to 48khz, 320kbps, CBR & VBR,
stereo sound
|
WMA(*.ASF)
|
WMA
7/8/9
up to 48khz, 192kbps, CBR stereo sound
|
Vivid Photo Viewer
|
JPEG (*.JPG)
|
Baseline YUV (No progressive), up to 4096x4096 pixels, max. file size
6Mbytes
|
|
GIF (*.GIF)
|
Static, up to 1024x768 pixels
|
BMP (*.BMP)
|
Monochrome, 8 bits indexed-color, RGB, RLE8, up to 1600x1200 pixels
|
Smart File Brower
|
File System
|
FAT32, the same type of file system that's found on Windows
based
computer
|
Data Management
|
Select File/Folder Copy between any storage media, File Deletion, Media
format
|
Built-in TV Tuner
|
|
NTSC/PAL CATV
|
Built-in Storage
|
NA
|
Menu Language Settings
|
English,
French, German, Spanish, Italian, Dutch, Japanese
|
Connectivity
|
Earphones, Audio & composite Video line in/out (RCA cable), IR
remote control, USB 2.0 High Speed device*
|
Memory Card Interface
|
CompactFlash
Type
I/II and Microdrive
, Memory Stick
Duo
and Pro Duo, SD, Mini-SD, Micro-SD, MMC, RS-MMC, MMC, RS-MMC, MMC-Mobile
|
Power source
|
External AC to DC adapter, 100-240V, 50-60Hz input, DC 5.0V. 1.5A
|
100-240V, 50-60Hz input DC 5.0V .2.6A
|
Dimensions
|
D87mm x W118mm x H32mm
|
Weight
|
160g / wo HDD
|
Package contents
|
Power Adapter, Remote Control, A/V Cablex2, USB Cable* , Quick Start
Guide and User Manual*
|
|
|
|
|
|
| |
|
| |
 |
Copyright 2000-2006 Meicheng |
|
|
